These cables are easy to mount and rodent-protected, suitable for underground, tubes and channel areas, where normal tensile stresses and/or transverse compressions occur and rodent infestation is to be expected.
| Fibre Type | ?Loose Tube. |
| Strain Relief | Glass yarns. |
| Armour | Glass yarns. |
| Sheath | PE. |
| Operating Temperatures | -20℃~+60℃ |
| Minimum Bending Radius | 150mm |
| Corrosive Gases | EN 50267-2 |
| UV Resistant | Yes |
| Longitudinally Water-tight | Yes |
| CONSTRUCTION | FIBRE TYPE | NOMINAL OVERALL DIAMETER | NOMINAL WEIGHT |
|---|---|---|---|
| NO. OF FIBRES | - | MM | KG/KM |
| 2~12 | Multimode G50/125 | 7.5 | 40 |
| 2~12 | Multimode G62.5/125 | 7.5 | 40 |
| 2~12 | Single-Mode E9/125 | 7.5 | 40 |
| 24 | Multimode G50/125 | 8.5 | 60 |
| 24 | Multimode G62.5/125 | 8.5 | 60 |
| 24 | Single-Mode E9/125 | 8.5 | 60 |
