Widely used in steel mills, foundries, and heat-treating furnaces where ambient temperatures exceed conventional cable limits. Ideal for internal wiring of industrial ovens, kilns, glass manufacturing equipment, and high-temperature lighting systems. Also suited for wiring in chemical processing plants, ceramic production lines, and power generation facilities where sustained 450°C heat resistance is critical to operational safety and circuit integrity.
| Size | Conductor Structure | Insulation | Jacket | Approx. O.D. |
|---|---|---|---|---|
| mm² | mm | mm | mm | |
| 0.14 | 7/0.16 | 0.45 | 0.20 | 1.8 |
| 0.22 | 7/0.20 | 0.45 | 0.20 | 1.9 |
| 0.25 | 7/0.23 | 0.45 | 0.20 | 2.0 |
| 0.50 | 16/0.20 | 0.45 | 0.20 | 2.2 |
| 0.75 | 24/0.20 | 0.45 | 0.20 | 2.4 |
| 1.0 | 32/0.20 | 0.45 | 0.20 | 2.6 |
| 1.5 | 30/0.25 | 0.45 | 0.20 | 2.9 |
| 2.0 | 40/0.25 | 0.45 | 0.20 | 3.1 |
| 2.5 | 50/0.25 | 0.45 | 0.20 | 3.3 |
| 4.0 | 56/0.30 | 0.45 | 0.20 | 3.9 |
| 6.0 | 84/0.30 | 0.69 | 0.25 | 5.1 |
| 10.0 | 140/0.30 | 0.69 | 0.25 | 6.4 |
| 16.0 | 224/0.30 | 0.69 | 0.25 | 7.6 |
| 25.0 | 350/0.30 | 0.69 | 0.25 | 9.0 |
