Designed for low-voltage instrumentation and control circuits in high-temperature zones. Commonly applied in appliance internal wiring, heating element connections, thermal sensor leads, and signal circuits within industrial furnaces and kilns. Well-suited for equipment where a 300V rating is sufficient but 450°C thermal endurance is essential — including laboratory furnaces, food processing ovens, textile machinery, and packaging equipment operating at elevated temperatures.
| Size | Conductor Structure | Insulation | Jacket | Approx. O.D. |
|---|---|---|---|---|
| mm² | mm | mm | mm | |
| 0.14 | 7/0.16 | 0.31 | 0.20 | 1.5±0.1 |
| 0.22 | 7/0.20 | 0.31 | 0.20 | 1.6±0.1 |
| 0.25 | 7/0.23 | 0.31 | 0.20 | 1.7±0.1 |
| 0.50 | 16/0.20 | 0.31 | 0.20 | 1.9±0.1 |
| 0.75 | 24/0.20 | 0.31 | 0.20 | 2.2±0.1 |
| 1.0 | 32/0.20 | 0.31 | 0.20 | 2.3±0.1 |
| 1.5 | 30/0.25 | 0.31 | 0.20 | 2.6±0.1 |
| 2.0 | 40/0.25 | 0.31 | 0.20 | 2.9±0.2 |
| 2.5 | 50/0.25 | 0.31 | 0.20 | 3.1±0.2 |
| 4.0 | 56/0.30 | 0.31 | 0.20 | 3.6±0.2 |
| 6.0 | 84/0.30 | 0.41 | 0.25 | 4.5±0.3 |
| 10.0 | 140/0.30 | 0.41 | 0.25 | 5.8±0.3 |
| 16.0 | 224/0.30 | 0.51 | 0.25 | 7.2±0.5 |
| 25.0 | 350/0.30 | 0.51 | 0.25 | 8.7±0.5 |
