Multicore Unscreened Armoured Cables-Belden Equivalent 28271

These multicore unscreened armoured cables are Type MC Metal Clad cables

Conductor: Bare copper wire

Insulation: XLPE.

Inner Sheath: FR PVC.

Armour: Steel wire armour

Outer Sheath: FR PVC

Insulation Colour: Black, White, Red, Green, Brown. Other colours are available upon your request.

AWG		12
CONDUCTOR CONSTRUCTION		7x20
NOMINAL CONDUCTOR DC RESISTANCE @20℃	Ω/KM	5
VOLTAGE RATING	V	600
BENDING RADIUS		13xOverall Diameter
OPERATING TEMPERATURE	℃	-40~90

ORDERING CODE	NO. OF PAIRS	INSULATION THICKNESS	SHEATH THICKNESS	OVERALL DIAMETER
		MM	MM	MM
BE1128271V SWA	5	0.8	1.7	19.72
