Steel Wire Cable Tray-Couplers, Fixings & Supports

Couplers

Preclic couplers

Pre-galvanised steel, hot dip galvanised or stainless steel.

Joint strips

Electroplated zinc, hot dip galvanised or stainless steel.

Faslock

  • Ordering Code Applicable Range
    Pre-galvanised steel
    CSFC200 up to 200 mm widths
    CSFC300 300 mm widths and above
    Dacromet
    CSFD200 up to 200 mm widths
    CSFD300 300 mm widths and above
    Stainless steel
    CSFS200 up to 200 mm widths
    CSFS300 300 mm widths and above

Luminaire support

Luminaire support can also be used as a base coupler. Type: pregalvanised steel, Dacromet or stainless steel.

Fixings

Nuts and coach bolts

  • Ordering Code Size
    Electroplated zinc
    CSNB0620 M6 x 20
    Dacromet
    CSNBD0620 M6 x 20
    Stainless steel
    CSNBS0620 M6 x 20

Hold down clamp

Type: Electroplated zinc, Dacromet or stainless steel

Turbo kits A

Kits comprise large clamp plate with integrated nut and small clamp plate with integrated bolt. Type: electroplated zinc or Dacromet.

Turbo kits B

Kits comprise small clamp plate with integrated bolt and M6 nut. Type: electroplated zinc or Dacromet.

Fixing kits A

Fixing kits A are used for general clamping of straight lengths and fittings. Kits comprise large clamp plate, small clamp plate, M6 nut and M6 x 20 coach bolt. Type: electroplated zinc, Dacromet or stainless steel.

Fixing kits B

Fixing kits B are used for general clamping where only one clamp plate is required (eg fixing plates). Kits comprise small clamp plate, M6 nut and M6 x 20 coach bolt. Type: electroplated zinc, Dacromet or stainless steel.

Channel strut clip

Type: Dacromet

Corner assembly

  • Ordering Code Depth
    　 mm
    Electroplated zinc
    CSCA028 28
    CSCA052 52
    CSCA102 102

Universal mounting plates


Type: pre-galvanised steel, hot dip galvanised or stainless steel. Not suitable for 28 mm tray depth.

Base Fixing Plates

For 50 mm widths and depths 28 and 52 mm only

Universal base fixing plates

Universal base fixing plates are used to flush fit tray to flat surfaces. Type: pre-galvanised steel, Dacromet or stainless steel.

Stand-off brackets (15mm depth)

Provide 15 mm clearance on flat or uneven surfaces. Type: pregalvanised steel, Dacromet or stainless steel.

Floor mount brackets (55mm depth)

Type: pre-galvanised steel, hot dip galvanised or stainless steel.

Channel fixing plates (40 mm width)

Type: pre-galvanised steel, Dacromet or stainless steel.



Supports

Vertical wall brackets (30 mm depth)

Vertical wall brackets are used for vertically mounting tray widths 150 mm and above. Type: pre-galvanised steel, hot dip galvanised or stainless steel.

Central hangers

Central hangers for use with 50 and 100 mm tray widths and depths 28 and 52 mm. Use with 6 or 8 mm threaded rod.

  • Ordering Code Width
    　 mm
    Pre-galvanised steel
    CSCHC050 50
    CSCHC100 100
    Hot dip galvanised
    CSCHG050 50
    CSCHG100 100
    Stainless steel
    CSCHS050 50
    CSCHS100 100

Central hangers for use with 200 to 600 mm tray widths and depths 28 and 52 mm. Use with 8, 10 or 12 mm threaded rod.

  • Ordering Code Width
    　 mm
    Pre-galvanised steel
    CSCHC200 200
    CSCHC300 300
    CSCHC400 400
    CSCHC450 450
    CSCHC500 500
    CSCHC600 600

Suspension plates

For use with 100 and 200 mm tray widths and depths 28 and 52 mm. Use with 6 or 8 mm threaded rod. Type: pre-galvanised steel or Dacromet.

Suspension hooks

For use with all tray widths and depths. Type: pre-galvanised steel, hot dip galvanised or stainless steel.
