    Type G Two-Conductor Flat Portable Power Cable 2kV

    • Type G Two-Conductor Flat Portable Power Cable 2kV
    • Type G Two-Conductor Flat Portable Power Cable 2kV

    Application

    These flat parallel cables are designed for use on D.C. off-track mining equipment, such as D.C. shuttle cars, drills, cutting and loading machines.

    Standards

    • ICEA S-75-381/NEMA WC 58
    • ASTM B 172
    • ASTM B 33
    • CAN/CSA C22.2 No. 96

    Construction

    Conductors Stranded annealed tinned copper conductor.
    Insulation Ethylene Propylene Rubber (EPR).
    Grounding Conductor Tinned copper conductor with an optional green outer covering.
    Reinforcement Synthetic yarn.
    Jacket Reinforced heavy-duty/extra-heavy-duty Chlorinated Polyethylene (CPE), black. (Cables having a nominal outside diameter of more than 2.0 inches require extra-heavy-duty jackets.)

    Options

    Other jacket materials such as CSP/PCP/NBR/PVC are available upon request.
    Two-layer jacket with reinforcing fibre between the two layers can be offered as an option.

    Mechanical and Thermal Properties

    Minimum Bending Radius 6×OD
    Maximum Conductor Operating Temperature +90℃

    Dimensions and Weight

    Construction No. of Strands Grounding Conductor Size Nominal Insulation Thickness Nominal Jacket Thickness Nominal Overall Diameter Height×Width Nominal Weight Ampacity
    No. of cores × AWG/kcmil - AWG/kcmil inch mm inch mm inch mm lbs/kft kg/km A
    2×6 133 8 0.06 1.5 0.080 2.0 0.56×1.02 14.2×25.9 500 744 95
    2×4 259 7 0.06 1.5 0.095 2.4 0.61×1.15 15.5×29.2 635 945 127
    2×3 259 6 0.06 1.5 0.095 2.4 0.68×1.26 17.3×32.0 785 1170 145
    2×2 259 5 0.06 1.5 0.095 2.4 0.73×1.35 18.5×34.3 935 1390 167
    2×1 259 4 0.08 2.0 0.110 2.8 0.81×1.55 20.6×39.4 1185 1760 191
    2×1/0 259 3 0.08 2.0 0.125 3.2 0.93×1.67 23.6×42.4 1470 2190 217
    2×2/0 329 2 0.08 2.0 0.125 3.2 0.99×1.85 25.1×47.0 1790 2660 250
    2×3/0 413 1 0.08 2.0 0.140 3.6 1.03×2.00 26.2×50.8 2145 3190 286
    2×4/0 532 1/0 0.08 2.0 0.140 3.6 1.10×2.10 27.9×53.3 2545 3790 328

    Ampacity-Based on a conductor temperature of 90℃ and an ambient air temperature of 40℃, per ICEA S-75-381.
