    RG7H1R for Airport Lighting Cables

    Applications

    These cables are used as airfield lighting equipment primary cables for the series circuit connecting the Constant Current Regulators and the isolasting transformers, and between the isolating transformers.

    Standards

    ENV 50213

    Construction

    Conductor: Compact stranded bare copper conductor.
    Inner Semi-Conductor: Extruded semi-conducting compound.
    Insulation: High module rubber compound, G7 type.
    Outer Semi-Conductor: Extruded semi-conducting compound.
    Shield: Bare copper tapes.
    Sheath: PVC.

    Technical Data

    Rated Voltage Uo/U (Um) 3.6/6kV
    Maximum Conductor Temperature 90℃
    Short Circuit Temperature 250℃
    Operating Temperatures 0℃~+90℃
    Minimum Bending Radius 15×OD
    Flame Retardant Yes

    Dimensions and Weight

    Construction Nominal Insulation
    Thickness
    Minimum Shield
    Thickness
    Nominal Sheath
    Thickness
    Nominal Overall
    Diameter
    Nominal Weight
    No. ×mm² mm mm mm mm kg/km
    1×10 2.3 0.075 1.4 14.0 305
